Waller

Beautiful gradient wallpapers for Android — generated, previewed, and applied in seconds.





---

✦ Table of Contents

• Highlights
• Features
• Download
• Getting Started
• Permissions
• How It Works
• Key Files / Structure
• Adding a New Effect
• Troubleshooting
• Contributing
• Community
• License

---

✦ Highlights

🎨 4 Gradient Styles	Linear, Radial, Angular (sweep), Diamond — each with a 0°–360° rotation slider
✨ 5 Visual Effects	Snow, Stripes, Glass overlay, Geometric grid, Blur — each with individual opacity
👁 Live Preview Mode	Fullscreen overlay to tweak style, angle & effects before applying
❤️ Favourites	Snapshot any wallpaper including exact effects & alphas; import/export as .wall
📤 Share Anywhere	Export as PNG, .wall, SVG, or production-ready CSS
🎛 Two Interaction Modes	Simple (tap → apply) or Advanced (tap → live preview)
🎵 Haptic Feedback	Toggleable, context-sensitive — snaps at 90° angle checkpoints
🔔 Auto Update Check	Silent GitHub releases check on launch
💎 Material You	Dynamic color, floating nav bar, animated chips, spring physics

---

✦ Features

Wallpaper Generation

• Generate grids of 12, 16, or 20 wallpapers per refresh.
• Portrait (9:16) and Landscape (16:9) preview and bitmap output.
• Select up to 5 custom colors via HSV picker, or let the app generate random palettes.
• Three tone modes: Dark, Neutral, Light — applied during color generation and shading.
• Multi-color mode produces 3–5 stop gradients.
• Toggle any combination of gradient types per session.

Effects

Effect	Description
❄️ Snow	Film-grain-style random white specks
〰️ Stripes	Diagonal translucent stripe pattern
🪟 Glass	Nothing-style subtle glass overlay
🔲 Geometric	Grid and circle line overlay
💧 Blur	Full-image Stack Blur — pure Kotlin, no RenderScript

Each effect has a 0–100% opacity slider in Advanced mode. Effects are snapshotted with favourites so the saved look is reproduced exactly on any device.

Advanced Preview Overlay

• Fullscreen wallpaper render in a device-frame style box.
• Switch gradient style and drag the angle slider without leaving the preview.
• Angle slider snaps to 90° increments with haptic feedback.
• Per-effect chips with a fill-progress bar showing current alpha.
• Heart button inside preview to favourite the current configuration.
• Done opens the apply/download dialog directly from the overlay.

Favourites

• Heart any wallpaper from the grid or inside the preview.
• Favourites store the exact effect flags and opacities at save time.
• Reverse-chronological grid; supports portrait/landscape toggle.
• Import individual .wall files or bulk-import multiple at once.
• Export all favourites as a single .wall file to share or back up.

Apply & Share

• Apply to Home screen, Lock screen, or Both.
• Download as PNG to Pictures/Waller via MediaStore.
• Share as PNG bitmap, .wall file, SVG, or CSS.
• SVG export mirrors BitmapUtils rendering math exactly (gradient anchoring, stripe pattern, noise filter, base64 overlays).
• CSS export produces ready-to-use classes with linear-gradient / conic-gradient / radial-gradient and filter: blur() — paste straight into a project.

Settings

Setting	Options
App theme	System / Light / Dark
Gradient background	On / Off
Haptics	On / Off
Interaction mode	Simple / Advanced
Default orientation	Auto / Portrait / Landscape
Default gradient count	12 / 16 / 20
Default tone mode	Dark / Neutral / Light
Default multicolor	On / Off
Default effects	Snow / Stripes / Glass pre-enabled

---

✦ Download



Grab the latest .apk from the Releases page. Pre-releases are clearly labelled — beta builds often ship new effects or UI experiments ahead of the stable channel.

---

✦ Getting Started

git clone https://github.com/Pankaj-Meharchandani/Waller.git
cd Waller

Open in Android Studio (Flamingo or newer), let Gradle sync, then run on a device or emulator.

Or from the command line:

./gradlew assembleDebug
./gradlew installDebug

Tip: To open a .wall file from a file manager or another app, just tap it — Waller registers itself as a handler for application/octet-stream via an intent filter in the manifest.

Requirements:

• Android Studio Flamingo or newer
• Kotlin (matching the project Kotlin version)
• Jetpack Compose with Material3
• Min SDK API 26 (Android 8.0) · Tested on Android 11–14
• Blur preview requires API 31+ and degrades gracefully on older devices

---

✦ Permissions

Permission	When required
WRITE_EXTERNAL_STORAGE	API ≤ 28 only — saving PNGs to Pictures/Waller
SET_WALLPAPER	Normal permission, no runtime prompt needed
INTERNET	Update checker — one GitHub API call per launch

On API 29+ the app uses MediaStore with RELATIVE_PATH and IS_PENDING — no storage permission required. Lock-screen wallpaper (WallpaperManager.FLAG_LOCK) works on API 24+; behavior on some OEM skins (MIUI, One UI) may vary.

---

✦ How It Works

Color Generation

ColorUtils.kt works in HSV space to apply tone-biased generation. generateRandomColor(toneMode) clamps the value (brightness) channel to a range matching the selected tone. createShade(color, toneMode, subtle) produces close variations with small hue/saturation/value deltas — making palette pairs feel cohesive rather than arbitrary.

Bitmap Rendering (BitmapUtils.kt)

When applying or downloading, createGradientBitmap() draws into an Android Canvas in layer order:

1. Gradient — LinearGradient, RadialGradient, or SweepGradient shader via drawRect.
2. Snow — random white circles at ~2% pixel density with randomized alpha.
3. Stripes — canvas rotated −45°, soft-fade gradient rects at width/12 spacing.
4. Glass overlay — overlay_stripes.png scaled to canvas with per-alpha Paint.
5. Geometric overlay — overlay_geometric.png scaled to width with per-alpha Paint.
6. Blur — pure-Kotlin Stack Blur (stackBlur()), radius 1–25 px scaled by blurAlpha. Applied last so it affects the fully composited image.

Compose Preview Rendering

WallpaperItemCard and PreviewWallpaperRender mirror the same pipeline using Compose Brush, Canvas drawscope, and Image composables. Angular gradients use a SweepGradient shader drawn via nativeCanvas since Compose's sweep brush doesn't support rotation. Blur uses RenderEffect.createBlurEffect() (API 31+) on a graphicsLayer wrapping only the gradient/effects — keeping the bottom type/color tag sharp outside the blur group.

Favourites Persistence

Favourites are encoded as a delimited string in SharedPreferences. Each entry stores: gradient type, hex color list, 5 effect flags, angle, and 5 alpha floats. The format is backward-compatible — older entries missing alpha fields default to 1f.

.wall File Format

A .wall file is JSON produced by kotlinx.serialization:

{
  "version": 1,
  "walls": [
    {
      "colors": [-13421773, -6710887],
      "gradientType": "Linear",
      "angleDeg": 135.0,
      "addNoise": false,
      "addStripes": true,
      "addOverlay": false,
      "addGeometric": false,
      "addBlur": false,
      "noiseAlpha": 1.0,
      "stripesAlpha": 0.6,
      "overlayAlpha": 1.0,
      "geometricAlpha": 1.0,
      "blurAlpha": 1.0
    }
  ]
}

Colors are ARGB Int values. Multiple wallpapers can be packed into one file for bulk sharing or backup.

---

✦ Key Files / Structure

ui/
├── WallerApp.kt                     # Root composable, global state, navigation, persistence
├── wallpaper/
│   ├── WallpaperModels.kt           # Wallpaper, GradientType, ToneMode, FavoriteWallpaper
│   ├── WallpaperGeneratorScreen.kt  # Home screen — grid, options panel, refresh
│   ├── FavoritesScreen.kt           # Favourites grid, import/export, preview
│   ├── ApplyDownloadDialog.kt       # Apply / Download / Share dialog
│   ├── BitmapUtils.kt               # Bitmap rendering, save, apply, Stack Blur
│   ├── ColorUtils.kt                # HSV helpers, random color generation, shading
│   ├── WallpaperSessionState.kt     # Per-session state (colors, scroll, gradient types)
│   ├── ShareUtils.kt                # PNG / SVG / CSS share helpers
│   ├── Haptics.kt                   # Global haptic feedback wrapper
│   └── InteractionMode.kt           # SIMPLE / ADVANCED enum
│   └── components/
│       ├── WallpaperItemCard.kt     # Grid preview card (Compose Canvas rendering)
│       ├── CompactOptionsPanel.kt   # Effect/gradient/tone/color chips row
│       ├── Header.kt                # App title + orientation chip
│       ├── FloatingNavBar.kt        # Animated floating navigation bar
│       ├── EffectsSelector.kt       # Switch list (Settings context)
│       └── previewOverlay/
│           ├── WallpaperPreviewOverlay.kt    # Fullscreen preview screen
│           ├── PreviewWallpaperRender.kt     # Stateless preview renderer
│           ├── PreviewRenderer.kt            # Brush/shader factory functions
│           ├── PreviewControlsComponents.kt  # Effect chips, sliders, gradient selectors
│           └── PreviewState.kt               # Default alpha constants
├── wallfile/
│   ├── WallFile.kt                  # Serializable data classes for .wall format
│   ├── WallFileManager.kt           # Import / export / share .wall files
│   ├── WallConverters.kt            # FavoriteWallpaper ↔ WallFavorite converters
│   └── SvgExporter.kt               # SVG and CSS file generation
├── settings/
│   ├── SettingsScreen.kt            # Settings UI
│   └── AboutScreen.kt               # About screen with links
└── onboarding/
    ├── OnboardingModeDialog.kt      # First-launch mode picker
    ├── UpdateAvailableDialog.kt     # Update available dialog
    └── UpdateChecker.kt             # GitHub releases API check

---

✦ Adding a New Effect

The architecture is designed so adding a new effect touches two core files plus a handful of wiring files:

Core (rendering logic):

1. WallpaperModels.kt — add the boolean flag and alpha Float to FavoriteWallpaper.
2. BitmapUtils.kt — add a drawing block in createGradientBitmap().

Wiring (plumbing the new state through):

• WallFile.kt + WallConverters.kt — extend the serializable format and converter.
• CompactOptionsPanel.kt — add an entry to the effects list (icon key + label).
• WallpaperPreviewOverlay.kt — add an EffectConfig entry and a slider when branch.
• WallpaperItemCard.kt + PreviewWallpaperRender.kt — add the Compose Canvas rendering blocks.
• WallerApp.kt + WallpaperGeneratorScreen.kt + FavoritesScreen.kt — thread state through the call chain.

Architectural note: The dual rendering path (Compose Canvas in WallpaperItemCard vs. Android Canvas in BitmapUtils) is a known tension. A future refactor toward a shared EffectRenderer interface would reduce the per-effect file count to 2.

---

✦ Troubleshooting

Bitmap looks low resolution on some devices getScreenSizeForBitmap() uses currentWindowMetrics (API 30+) and subtracts system bar insets. On unusual OEM configurations the returned dimensions can be smaller than expected.

Blur has no visual effect in preview The Compose RenderEffect blur requires API 31+. On API 30 the blur chip still works but the preview render is a no-op. The bitmap blur (stackBlur) works on all API levels.

Lock screen apply does nothing Some OEM skins (MIUI, One UI) restrict programmatic lock-screen changes. The app falls back to FLAG_SYSTEM silently — no crash, but the toast will show the failure message.

Save fails on Android 8 or 9 Grant WRITE_EXTERNAL_STORAGE when prompted. The app requests it at the point of saving on API ≤ 28.

Gallery doesn't show the saved image On API 29+ MediaStore insertion with IS_PENDING = 0 surfaces the file immediately. On older versions a media scanner broadcast is sent. If it still doesn't appear, reboot or navigate to Pictures/Waller in a file manager.

.wall file not recognized by the picker The picker launches with */* since .wall has no registered MIME type. The app filters to .wall extension after selection, falling back to all selected files if none match.

---

✦ Contributing

Contributions are welcome!

1. Fork the repo and create a feature branch: git checkout -b feat/my-feature
2. Commit with a clear message: git commit -m "Add my feature"
3. Push and open a pull request.

Please:

• Keep both rendering paths (Compose + Android Canvas) in sync when touching effect logic.
• Test on both API 30 and API 31+ (blur behavior differs).
• Run through portrait and landscape for any UI change.
• Prefer stdlib/regex over new third-party dependencies for simple tasks.

---

✦ Community

---

✦ License

This project is licensed under the GPL License. See the LICENSE file for details.

---
