claude-xcindex

Semantic Swift/ObjC symbol lookups for Claude Code — powered by Xcode's on-disk SourceKit index.

⚡ Sub-ms warm queries · 🎯 ~200× faster than grep · 📉 Up to 70% fewer files read

---

A Claude Code plugin that gives Claude semantic access to Xcode's on-disk symbol index. Refactors, reference lookups, and impact analysis on Swift/ObjC projects stop falling back to grep-and-read-file — and start hitting the same library SourceKit-LSP uses.

✨ Features

• Lightning fast. Sub-millisecond warm queries after the first call — roughly 200× faster than grep -rn on the same source tree.
• Semantic, not textual. USR-authoritative references, overrides, conformances, blast-radius. Finds what grep can't — protocol witnesses, extensions, @objc bridging, module-scoped name collisions.
• Zero re-indexing. Reads the same IndexStoreDB Xcode writes during build. No daemon, no second copy of your codebase.
• Honest about freshness. Warns at session start if source is newer than the index. Annotates results in files Claude edited locally. Never builds on your behalf.

→ Full numbers, methodology, and per-symbol precision in docs/benchmarks.md.

🧠 Why

Claude's default answer to "where is UserService used?" is ripgrep — 40 noisy textual matches, 8 full files read to disambiguate. Expensive in tokens, imprecise in results. Xcode already solved this: every build writes a full semantic index to DerivedData. Apple's indexstore-db library queries it. This plugin wraps those queries behind MCP tools so Claude reaches for the index instead of grep — and reads only the lines that matter.

🔧 How

Claude Code
    ↓ (MCP over stdio)
claude-xcindex plugin
├── Skills          — tell Claude WHEN to use the index
├── Hooks           — freshness warnings at session start and after edits
├── Subagent        — isolated context for large renames
├── Slash commands  — /xcindex-setup, /xcindex-status
└── Swift binary    — MCP server, queries IndexStoreDB
    ↓ (reads LMDB)
DerivedData/Index.noindex/DataStore
    ↑ (writes during build)
Xcode

One native Swift binary, speaking MCP directly via Anthropic's Swift SDK. No Node runtime, no intermediate process.

→ Full mental model (freshness, DerivedData resolution, USR-first lookups) in docs/how-it-works.md.

MCP tools

Exposed under mcp__xcindex__*. Signatures and examples in docs/tools-reference.md.

Tool	Purpose
find_symbol	Name → candidate USRs with kind and defining file.
find_references	Every occurrence with file, line, column, role.
find_definition	The canonical definition site.
find_overrides	All overriding implementations of a method.
find_conformances	All types conforming to a protocol.
blast_radius	Minimal set of files affected by editing a file.
status	Index freshness, DerivedData path, last-build timestamp.

Skills & hooks

• swift-find-references — triggers on "where is X used?". Steers Claude off grep.
• swift-blast-radius — triggers on "what does this file affect?". Skips shotgun reads.
• swift-rename-symbol — triggers on rename requests. Delegates to a subagent so the main context doesn't balloon.
• SessionStart hook — reports index freshness up front.
• PostToolUse hook — tracks Swift/ObjC edits so stale results are annotated. Never triggers a build.

🛠 Requirements

• macOS 14 (Sonoma) or later — indexstore-db requires macOS 14+.
• Xcode 16 or later with command-line tools (xcode-select --install).
• Claude Code.
• An Xcode project (.xcodeproj / .xcworkspace) built at least once.

📦 Install

Note

Marketplace submission pending. claude-xcindex is awaiting approval for the official Anthropic plugin marketplace. In the meantime, install it by adding this repo as a local marketplace — same plugin, one extra step.

From inside Claude Code:

/plugin marketplace add drewalth/claude-xcindex
/plugin install claude-xcindex@claude-xcindex-local

First run downloads the matching xcindex binary from the GitHub release and caches it under the plugin directory — no npm install, no manual build.

Then, in a Swift project:

/xcindex-setup

This confirms the binary is ready, locates your Xcode project, and — with your confirmation — runs xcodebuild per scheme so the index is populated. Skip it if you build in Xcode yourself.

Verify with /plugin and /xcindex-status. If anything looks off, run ./bin/xcindex-doctor.

Install from a local clone

Useful for pinning to a specific commit or hacking on the plugin:

git clone https://github.com/drewalth/claude-xcindex.git
cd claude-xcindex/service && swift build -c release

Then in Claude Code:

/plugin marketplace add /absolute/path/to/claude-xcindex
/plugin install claude-xcindex@claude-xcindex-local

The launcher detects the from-source build at service/.build/release/xcindex and symlinks it instead of downloading.

🚀 Usage

Once installed, the skills trigger automatically based on what you ask.

Natural-language triggers:

• "Where is UserService used?"
• "What calls fetchUser?"
• "What depends on NetworkClient.swift?"
• "What will break if I change AuthManager?"
• "Rename fetchUser to loadUser across the codebase."
• "What tests cover ModelData.swift?"

Explicit: /xcindex-status checks index freshness and reports which files have been edited since the last build.

You: Find all callers of fetchUser.
Claude: [mcp__xcindex__find_symbol → mcp__xcindex__find_references]
        → 6 call sites across 4 files. Reads ±10 lines around each.
        Returns a focused summary instead of 8 full-file reads.

🤝 Complementary tools

This plugin focuses on semantic queries over Xcode's on-disk index. It is not a language server and does not build, test, or run your project. Pair it with:

Anthropic's swift-lsp

Live LSP features (completion, diagnostics, hover) backed by SourceKit-LSP. Different layer: swift-lsp is an editor-UI integration (no MCP tools the agent can call); claude-xcindex exposes semantic queries to the agent loop. They don't overlap.

	swift-lsp	claude-xcindex
Backend	SourceKit-LSP server	indexstore-db reader
Source of truth	live Swift source	Xcode build-time index
Requires Xcode build?	No	Yes (once)
Diagnostics & completion	Yes	No
Hover / jump-to-definition	Yes	Definition only
Agent-callable MCP tools	No (editor-UI only)	7 tools
Overrides / conformances / blast-radius	Not first-class	Yes
Works on Linux / SwiftPM-only	Yes	No (DerivedData-specific)
Warm query latency	LSP round-trip	sub-millisecond
Freshness model	always live	hook-warned when stale

Build & test orchestration

• Apple's mcpbridge (ships with Xcode 26.3+) for build, test, preview, docs.
• XcodeBuildMCP for older Xcode versions.

🆚 Other Swift symbol tools

If you've already looked at the broader Swift-MCP space, here's where claude-xcindex sits relative to the closest neighbours:

	claude-xcindex	block/xcode-index-mcp	SwiftLens
Backend	indexstore-db (direct)	indexstore-db (direct)	SourceKit-LSP
Packaging	Claude Code plugin (skills + hooks + subagent)	Raw MCP server	Raw MCP server
Runtime	Native Swift binary	Python (uv) + Swift service	Python 3.10+
MCP tools	7 (find_symbol, find_references, find_definition, find_overrides, find_conformances, blast_radius, status)	4 (load_index, symbol_occurrences, get_occurrences, search_pattern)	15 (single-file analysis + cross-file refs/defs)
Overrides / conformances	Yes	No	No
Blast-radius analysis	Yes	No	No
Freshness warnings	Hook-driven, per-session	None	None
Status (Apr 2026)	Active	Active (~55⭐)	Archived 2026-03-10

block/xcode-index-mcp is the closest prior art — same backend, narrower tool surface, no plugin packaging. SwiftLens covered the same niche from the SourceKit-LSP angle but was archived in March 2026.

🩺 Troubleshooting

Run ./bin/xcindex-doctor — it checks Xcode, libIndexStore, the cached binary, and index freshness line-by-line with remediation hints. Full catalogue in docs/troubleshooting.md.

🧑‍💻 Development

./build.sh --debug          # debug build
cd service && swift test    # run tests

claude-xcindex/
├── .claude-plugin/plugin.json     # plugin manifest
├── .mcp.json                      # MCP server registration
├── bin/run                        # launcher
├── service/                       # Swift MCP server
├── skills/                        # find-refs, blast-radius, rename
├── agents/swift-refactor-specialist.md
├── commands/                      # /xcindex-setup, /xcindex-status
├── hooks/                         # session-start.sh, post-edit.sh
└── build.sh

PRs welcome — see CONTRIBUTING.md. Please open an issue to discuss architectural changes first.

📚 Prior art

• apple/indexstore-db — the query library this plugin wraps.
• block/xcode-index-mcp — closest prior art, Python + Swift MCP server for Goose/Cursor.
• michaelversus/SwiftFindRefs — CLI with the same core query.

🔒 Privacy

Runs entirely on your local machine. No telemetry, no analytics, no tracking. The only network request is to GitHub to download the prebuilt binary on first run. All queries run locally against Xcode's on-disk index.

📄 License

MIT — see LICENSE.
